| Specification | |
| Specification | Binocular Head Inclined At 30º,Rotatable 360º. Interpupil Distance 55-75mm |
| Eyepiece: | WF10X |
| Objective: | 4X, 10X, 40X(S), 100X(S) Oil |
| Condenser: | Abbe Condenser With Iris Diaphragm & filter N.A.1.25 |
| Focusing: | Coaxial coarse & fine focus adjustment |
| Fine focussing scale value:0.002mm | |
| Pixels: | 640X480 |
| Interface: | USB |
| Soft ware: | Driving soft ware, process soft ware, measuring soft ware(option) |
| Light source: | Input 220V/50Hz or 110V/60Hz output 6V/20W |
| Halogen tungsten bulb Adjustable brightness, Kohler illumination | |
| Selective parts: | Eyepiece:WF16X.WF20X |
| Objective:60X(S),20X | |
