| Specification | |
| Viewing Head: | Binocular Head(Inclined At 45º,360ºRotatable) |
| Eyepiece: | WF10X |
| Objective: | 4X, 10X, 40X(S), 100X(S) Oil |
| Interpupil Distance: | 55-75mm |
| Stage: | Double Layers Mechanical Stage |
| Stage Size:135*130mm | |
| Moving Range:70*30mm | |
| Condenser: | Abbe N.A.1.25 Condenser With Iris Diaphragm & Filer |
| Focusing Range: | 30mm |
| Fine Focusing Scale Value: | 0.002mm |
| Power: | Halogen Tungsten Bulb 220V/110V?6V/20W |
| Adjustable Brithtness | |
| SElective Parts: | Eyepiece:WF16X, WF20X, P16X |
| Objective:20X(S), 60X(s) | |
| Semi-Plane Field | |
| Plane Field | |
| Mirror | |
| Demonstration Head | |
| CCD Adapter | |
